Map Book Generator

When configured, it represents a modal window that allows users to input and submit queries to obtain GIS data of the selected entry as a map file in pdf format.

Map Book Generator configuration settings

Field	Description	Visualization
Name	Can be set any name Name will not be visible in Clearion Web
Base URL	URL to ArcGIS server where Map Book Generating flow is taking place Provided by the Clearion team If there are several projects in one workspace, for example, the Test project and the Prod project, in which the MapBook Widgets links are different, the following logic works: If the names of a pair of widgets match, the links will not be overwritten when merging projects if the names of a pair of widgets are empty or do not match, the links will be overwritten when merging projects, that is, the link from the source project will be set instead of the link in the recipient project
Result Data Type	“File” by default
Texts	Texts represent messages that the user sees on different steps of the Map Book generation process. Texts: Form Header On Submit Title - text that is used for the pop-up header when Map Book flow is started. On Submit Msg - text that is used for the pop-up body when Map Book flow is started. On Succeeded Title - text that is used for the pop-up header when Map Book flow is completed. On Failed Title - text that is used for the pop-up when Map Book flow is not completed.
Parameters	Parameters represent Map Book modal fields Parameters can be added manually via Add Column Parameters can be added automatically via Generate Fields: select an appropriate table select all the necessary fields Settings: Header Text - can be added any text which represents a column name Field - should correspond to a field name in a table Type - field type should be specified Lookup Key - lookup should be added if this is a lookup field Is Active - determines if the field is visible or hidden by default.
Role	Customizes widget settings for a specific role including URL and modal fields
Save	Saves the configuration
Export / Import	Please see the article on this topic Widget Export and Import
